Dr Lakaemper,
Here are my two programs for hw6. The first works fine. In
the second program I used another parameter that controls how much the
coefficients of higher frequencies are emphasized before applying threshold,
but that did not give any good results.
Uros Midic
uros@ist.temple.edu
Phone
+215.204.5908
FAX
+215.204.5082
Temple University, 303A Wachman
Hall, 1805 N. Broad St.,
Philadelphia, PA
19122
Attachment: hw6_part2.m (2k bytes) Open
% disp('This program uses a threshold (on absolute values)')
% disp('to discard Fourier coefficients.')
% disp('For nine different thresholds the program')
% disp('shows the image obtained after Fourier coefficients')
% disp('are discarded, and also displays the threshold,')
% disp('the percentage of discarded (i.e. set to 0)')
% disp('coefficients, and the MSE.')
% disp(['Keep in mind that 1/256 = ',num2str(1/256)])
% disp('This MSE value is reached with approximately')
% disp('50% of discarded coefficients,')
% disp('but fairly good results are obtained even with')
% disp('appr. 70% of discarded coefficients.')
% pause
dist = min(repmat([100:-1:0 1:99],[200 1]), repmat([100:-1:0 1:99]',[1 200]));
zeroims = cell(1,9);
im = imread('100_2007.jpg');
im = im2double(im);
im = 0.6*im(:,:,1)+0.3*im(:,:,2)+0.1*im(:,:,3);
im = im(51:250,101:300);
f = fft2(im);
fs1 = fftshift(f);
for k=[0 0.0001 0.0002 0.0005 0.001 0.002 0.005 0.01 0.02 0.05 0.1 0.2 0.5 1 2 5 10]
fs = fs1.*(1+dist*k);
for i=1:9
fs2 = fs;
t = 2^(-7-i);
zeroims{i} = (abs(fs2/(200*200))>=t);
fs2 = fs2.*zeroims{i};
fs2 = fs2./(1+dist*k);
f2 = ifftshift(fs2);
recim =ifft2(f2);
recerror = mse(recim(:)-im(:));
subplot(3,3,i);
imshow(recim);
title(['k = ',num2str(k),' t = ',num2str(t,5),'
zeros = ',num2str(100*sum(fs2(:)==0)/(200*200),3),'%
sqrt(mse)=',num2str(sqrt(recerror),5)]);
end
pause
for i=1:9
subplot(3,3,i);
imshow(zeroims{i});
end
pause
end
Attachment: 100_2007.jpg (70k bytes) Open
Attachment: hw6_part1.m (2k bytes) Open
disp('This program uses a threshold (on absolute values)')
disp('to discard Fourier coefficients.')
disp('For nine different thresholds the program')
disp('shows the image obtained after Fourier coefficients')
disp('are discarded, and also displays the threshold,')
disp('the percentage of discarded (i.e. set to 0)')
disp('coefficients, and the MSE.')
disp(['Keep in mind that 1/256 = ',num2str(1/256)])
disp('This MSE value is reached with approximately')
disp('50% of discarded coefficients,')
disp('but fairly good results are obtained even with')
disp('appr. 70% of discarded coefficients.')
pause
zeroims = cell(1,9);
im = imread('100_2007.jpg');
im = im2double(im);
im = 0.6*im(:,:,1)+0.3*im(:,:,2)+0.1*im(:,:,3);
im = im(51:250,101:300);
f = fft2(im);
fs = fftshift(f);
for i=1:9
fs2 = fs;
t = 2^(-7-i);
zeroims{i} = (abs(fs2/(200*200))>=t);
fs2 = fs2.*zeroims{i};
f2 = ifftshift(fs2);
recim =ifft2(f2);
recerror = mse(recim(:)-im(:));
subplot(3,3,i);
imshow(recim);
title(['t = ',num2str(t),' zeros =
',num2str(100*sum(fs2(:)==0)/(200*200),5),'%
sqrt(mse)=',num2str(sqrt(recerror))]);
end
pause
for i=1:9
subplot(3,3,i);
imshow(zeroims{i});
end
|
